Description
This item is brand-new, factory sealed.
*Diameter: 12-in *Rated impedance: 8 Ohms; or 16 Ohms; *Sensitivity: 98dB *Nominal diameter: 305mm / 12-in *Power rating: 70W *Rated impedance: 8 Ohms; or 16 Ohms; *Sensitivity: 98dB *Chassis type: Pressed steel *Magnet type: Ceramic *Magnet weight: 0.88kg / 31oz *Voice coil diameter: 1.75-in / 44mm *Voice coil material: Round copper *Frequency range: 70-5000Hz *Resonance frequency, Fs: 75Hz *DC resistance, Re: 7.3 Ohms; or 12.9 Ohms; *Cut-out diameter: 283mm / 11.1-in *Diameter: 309mm / 12.2-in *Magnet structure diameter: 134mm / 5.3-in *Mounting hole dimensions: 7.9mm / 0.31-in Diameter *Mounting hole PCD: 297mm / 11.7-in *Number of mounting holes: 8 *Chassis depth (inc gasket): 94mm / 3.70in *Magnet depth: 30mm / 1.18-in *Overall depth: 123mm / 4.8-in *Unit weight: 3.3kg / 7.2lb
8 Ohms; Frequency Response [Each]
