CELESTION FTR082011D 8 Mid Bass

Description

This item is brand-new, factory sealed.

*Continuous power rating: 400W *Sensitivity: 93dB *Voice coil diameter: 2-in *Nominal diameter: 200mm / 8-in *Power rating: 200W *Continuous power rating: 400W *EIA power rating: 350W *Rated impedance: 8 Ohms; *Sensitivity: 93dB *Frequency range: 70-6000Hz *Chassis type: Cast aluminium *Magnet type: Ferrite *Magnet weight: 1.2kg / 42oz *Voice coil diameter: 50mm / 2-in *Voice coil material: Round copper *Former material: Polyimide *Cone material: Kevlar loaded paper *Surround material: Cloth-sealed *Suspension: Single *Gap height (Hg): 8mm / 0.31-in *VC winding height (Hvc): 15mm / 0.59-in
Parameters *Sd: 226.98cm squared / 35.18-in squared *Fs: 86.10Hz *Mms: 27.75g / 0.98oz *Qms: 2.238 *Qes: 0.541 *Qts: 0.436 *Re: 5.82 Ohms; *Vas: 8.99l / 0.32ft cubed *BI: 12.71Tm *Cms: 0.12mm/N *Rms: 6.71kg/s *Le (at 1kHz): 0.38mH *Xmax: 5.5mm / 0.22-in
Mounting Information *Overall diameter: 225mm / 8.8-in *Overall depth: 102mm / 4-in *Cut-out diameter: 187mm / 7.4-in *Mounting hole dimensions: 6.5mm / 0.26-in Diameter *Number of mounting holes: 8 *Mounting hole PCD: 210mm / 8.3-in *Unit weight: 3.65kg / 8lb
Packed Dimensions & Weight *Single pack size W x D x H: 226mm x 226mm x 130mm / 8.9-in x 8.9-in x 5.1-in *Single pack weight: 3.8kg / 8.4lb *Multi pack qty: 8 *Multi pack size W x D x H: 470mm x 450mm x 270mm / 18.5-in x 17.7-in x 10.6-in *Multi pack weight: 31kg / 68lb
Frequency Response and Impedance Curves [Each]
