Description
This item is brand-new, factory sealed.
10GbE bandwidth and M.2 SSD cache, all at once
Synology E10M20-T1 helps you boost I/O performance and network bandwidth simultaneously using just one PCIe expansion slot on your Synology NAS.
10GbE ready
Achieve Multi-Gig Ethernet transmission speeds of up to 10 Gbps.
NVMe enabled
Accelerate random I/O performance with the dual M.2 2280/22110 NVMe SSD slots.
Dedicated cache slots
Free up primary drive bays for data storage.
A perfect match with Synology SNV3000 series NVMe SSD
Install Synology SNV3000 series NVMe SSD on the E10M20-T1 adapter card for fast and streamlined cache acceleration, and take full advantage of Synology SSDs enterprise-grade endurance, performance, and reliability with your Synology NAS.Hardware SpecificationsGeneralHost Bus Interface
PCIe 3.0 x8Bracket Height
Low Profile and Full HeightOperating Temperature
0oC to 40oC (32oF to 104oF)Storage Temperature
-20oC to 60oC (-5oF to 140oF)Relative Humidity
5% to 95% RHNotes
The warranty period starts from the purchase date as stated on your purchase receipt.StorageStorage Interface
PCIe NVMeSupported Form Factor
22110 / 2280Connector Type and Quantity
M-key, 2 SlotsNetworkIEEE Specification Compliance
IEEE 802.3an 10Gbps Ethernet
IEEE 802.3bz 2.5Gbps / 5Gbps Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Flow ControlData Transfer Rates
10 GbpsNetwork Operation Mode
Full DuplexSupported Features
9 KB Jumbo Frame
TCP/UDP/IP Checksum Offloading
Auto-negotiation between 100Mb/s, 1Gb/s, 2.5Gb/s, 5Gb/s, and 10Gb/sCompatibilityApplied ModelsNVMe SSD
SA series:SA3600, SA3400
20 series:RS820RP+, RS820+
19 series:DS2419+, DS1819+
18 series:RS2818RP+, DS3018xs, DS1618+
Features
Compatibility:
- SA series:SA6400, SA3610, SA3600, SA3410, SA3400
- 23 series:RS2423RP+, RS2423+
- 22 series:RS822RP+, RS822+, DS3622xs+, DS2422+
- 21 series:RS4021xs+, RS3621xs+, RS3621RPxs, RS2821RP+, RS2421RP+, RS2421+, RS1221RP+, RS1221+
- 20 series:RS820RP+, RS820+
- 19 series:DS2419+II, DS2419+, DS1819+
- 18 series:RS3618xs, RS2818RP+, DS3018xs, DS1618+
- 17 series:RS18017xs+, RS4017xs+, RS3617xs+, RS3617RPxs, DS3617xsII, DS3617xs
