No Logo 5207 Single-flush Dryer Receptacle [3 Wire]

Description

This item is brand-new, factory sealed.

Leviton 5207-S10 30 Amp, 125/250 Volt, NEMA 10-30R, 3P, 3W, Flush Mtg Receptacle, Straight Blade, Industrial Grade, Non-grounding, AL-CU, Side Wired, Steel Strap-Black

• Equipped with heavy-gauge, double-wire Copper alloy contacts
• Flush mount receptacles fit levitons wide range of 2.15-Diameter wallplates
• To ensure correct and speedy wiring, terminals have ID markings
• Warning: DO not use with single-gang wallboxes, single-gang mud rings or single-gang box extenders
• Use 2-gang wallplate (2.15″ opening) to complete installation
• Total Power Outlets : 1

• Part Number: 5207-S10
• Item Weight: 4 ounces
• Product Dimensions: 1.6 x 2.4 x 3.8 inches
• Item model number: 5207-S10
• Color: Black
• Voltage: 125 volts
• Item Package Quantity: 1
• Included Components: Device
• Batteries Included?: No
• Batteries Required?: No
• Warranty Description: 10-Year Limited

Leviton 5207-s00 is built of durable thermoplastic, Leviton power receptaclescome equipped with heavy-gauge, double-wire copper alloy contacts. To ensure correct and speedy wiring, terminals have id markings. Flush mount receptacles fit levitons wide range of 2.15-Diameter wallplates and mounting hardware is included.

Features

Additional Information:
Mechanical Specifications

• Terminal ID: Brass-Hot, Green-Ground, White-Neutral
• Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
• Terminal Accom.: Up to 4 AWG
